SUS304 Brackish Water RO Plant , PLC Seawater To Drinking Water Machine

Name: SUS304 Brackish Water RO Plant PLC Seawater To Drinking Water Machine
Brand: JISHUI
Price: 2000 USD

Quality SUS304 Brackish Water RO Plant , PLC Seawater To Drinking Water Machine for sale

Place of Origin : Guangdong, China

Brand Name : JISHUI

Packaging Details : plywood for salt sea water to drinking water machine

Price : 2000-4000

Applicable Industries : Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Construction works , Energy & Mining

After Warranty Service : Video technical support, Online support, Field maintenance and repair service

Local Service Location : None

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2020

Warranty of core components : 2 years

Core Components : Pressure vessel, Pump, Motor, PLC

Material : Fumigation wooden box, SUS304/316

After-sales Service Provided : Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Online support

Warranty : 1 Year

Productivity : 1000L/Hour

type : salt sea water to drinking water machine

Desalination rate : 99%

Color : natural color

Operation mode : automatic

RO membrane : 40-40In

transport : sea transportation

Application : Water Purification

Product name : Water Treatment System Processing Reverse Osmosis Plant

Contact Now

salt sea water to drinking water machine

Model	HY-1000LPH	Remark
Product Capacity	1m3/hr
Power supply	1PH x 220V, 50Hz
Feed water pump	Q= 2.5m3/h	GRUNDFOS/DENMARK
Sand filter	Φ400×1520(mm)	SUS304
Activated carbon filter	Φ400×1520(mm)	SUS304
Water softener	Φ400×1520(mm)	SUS304
Micron cartridge filter	Φ159×500(mm)	SUS304
1^st High pressure pump	Q= 2.5m3/h	GRUNDFOS/DENMARK
2^nd High pressure pump	Q= 1.25m3/h	GRUNDFOS/DENMARK
RO membrane	4040 8 pcs	HYDRANAUTICS/USA
RO membrane vessel	40480, 4 pcs	SUS304
UV sterilizer	18W	SUS304
Ozone generator	120W	SUS304

SUS304 Brackish Water RO Plant , PLC Seawater To Drinking Water Machine

Process flow

Haiyuan Company designs reasonable process according to user water requirements

Processing Diagram

Good materials, good quality

Features of Water Treatment

Pretreatment:

(1) Quartz sand/manganese sand filter

(2) Activated Carbon filter

(3) Softener and PP Filter

(4) Dosing system if need.

Main Machine of Water Treatment:

(1)Pumps;

(2)RO membrane (DOW/CSM/Hydranautics)

(3)Membrane Vessel(SS and FRP)

(4)PLC control/Relay control

(5)Optional UV sterlilizer&Ozone

Functions of Water Treatment:

A. Auto flush

B. Low pressure protection

C. High pressure protection

D. Back wash ® Eneration control

HaiYuan Workshop

Our Services

(1)100% factory tested before shipment

(2) 1 Year's Quality Warranty

(3) 2 Years of trouble free service offered

(4) Solve problems within 24 hours
